If you missed part one (posted yesterday), I encourage you to read it before moving to today’s continuation.  At the end of yesterday’s post, we arrived at a default 4th Down Strategy chart, essentially a cheat sheet that tells coaches when to go for it and when to punt/kick a FG.  For future reference, I have added the chart as a permanent fixture that can be accessed through one of the menu tabs at the top of the site.  That should make watching the games more fun (or frustrating since you’ll know in real-time when bad decisions are being made).

Today, we move to grading.  Using that chart, how do NFL Coaches perform?  As I mentioned yesterday, this research was done by Jared Cohen, you can follow him on twitter at @jaredscohen.

Fair warning, this is a very detailed analysis (more of a research project) and therefore is longer than the typical blog post.  Please read it when you have some time.  If that’s not possible, feel free to skip to the charts.

Part 2

Methodology

To examine 4^th down coaching decisions, I took the following steps.

1. Download a comprehensive set of all fourth down plays from the 2012 regular season, including a set of key variables I could track and control for, including:
   1. Distance to go for a first down/touchdown
   2. Quarter and clock time of the play (e.g., Q1, 14:30)
   3. Field position (e.g., own 35 yard line)
   4. Scoring margin (e.g., team up by 3 points)
2. Each play was segmented by the choice of its coach as either a punt, FG attempt, or conversion attempt (by rush or pass)
3. Based on the distance for conversion and field position, I compared the fourth down play call to the optimal strategy matrix (the strategy card), to see what the ‘right’ choice would be
4. A play call in which the coach made the optimal decision was termed a ‘Pass’, while a play call that was not (e.g., punting instead of aiming to convert 4^th down) was termed a ‘Fail’

Pretty simple right?

Now, before getting to any data, I should also note that I excluded a number of specific plays, for reasons which I’ll explain.  Remember, the goal of the analysis is to determine whether coaching decisions are optimal under normal circumstances.  The key word here is normal.

-        If  a team was either leading or trailing by more than 14 points (two touchdowns), we excluded the decisions, reasoning that coaches would be making decisions differently than normal behavior (e.g., trying to catch up)

-        If the distance required was longer than 10 yards (e.g., 4^th and 12 yards to go), I excluded it.  I did this largely because those situations usually aren’t decisions for the coach.  It’s a pretty clear field goal attempt or punt depending on where you are, and my major area of focus was on situations where a coach could decide to go for it

-        Plays were also excluded if they occurred in the last 2 minutes of the 2^nd quarter or the last 5 minutes of the 4^th quarter, as coaching behavior will also change significantly.  In the 2^nd quarter, it’s because a team can’t maintain possession.  In the 4^th quarter, it’s because the game is ending and teams will no longer be trying to maximize their total points, they’ll be more focused on gaining/maintaining a lead.

So while the aforementioned decisions could be interesting, they were in situations which are inherently not-normal.  The main goal is to see what coaches do in a typical situation.  Even after subtracting all these conditions, we have over 2,100 fourth down calls to evaluate.  That should be plenty.

So what did we see?

Results

We saw a pretty large number of failures.  I’d never want to play blackjack with these guys.

Below is a chart of the overall grade for NFL coaches’ fourth down decisions, by quarter.

Yes, you’re reading that right.  When making a decision as to what to do on 4^th down, the NFL coaching body as a whole makes the ‘optimal’ decision just slightly over half the time.

Think about that for a minute.  In just about half of all normal 4^th down situations, coaches are making decisions that fail to maximize their number of expected points (and we should expect, actual points).

That seems kind of strange.  And yet it also seems completely believable in a league where principally ALL coaches are far too conservative.

But if we spend some more time peeling back this coaching decision onion, we’ll look at a couple more specific cuts of the data that can give us more insight on exactly where these decisions are happening.

This will include:

-        Decisions by optimal decision (what kinds of decisions are the most frequently screwed up)

-        Decisions by field position (how do decisions vary by where you are on the field)

-        Decisions by yards to go (does optimal decision-making vary by distance)

-        Decisions by coach (which coaches appear to have the highest grades)

-        Decisions by scoring differential (does decision-making change when you’re ahead/behind)

-        Some fun with coaches (looking at specific game decisions to understand exactly what the implications are)

But before we get to that, there are a few caveats to all this analysis, which I want to make clear.  This is to head off complaints and anti-analytics folks who may have already commented about how I live in my mom’s basement.

1. This analysis accepts the illustrated decision matrix as optimal, when in reality, that may not hold completely.  It’s based on my interpretation of Brian Burke’s work, which I think is logical and is the leading model that I’ve seen. (I also ran these numbers with an alternative model generated for college football, and the results were consistent with expectations, which means they were much worse as college teams should kick field goals much less frequently than NFL teams do, hash marks and lower kicking talent level etc.)
2. These optimal decisions do not take into account the talent/performance of the teams in question.  It assumes equal teams are playing each other.  So could a team with a great offense merit different ‘optimal’ choices where they go for it more often?  Of course.  You could also adjust for the defense of your opponent, the skill of your kickers, the opposing punt return man, home field advantage, weather, or any recent lunar eclipse.  This doesn’t have any of those adjustments.
3. When we get into very granular cuts of data (specifically with coaches), we start to run into potential sample size issues.

All of this is to say that yes, there are concerns with this (or any) piece of analysis.  The goal of this isn’t to find incontrovertible proof, or establish new football dogma, it’s to investigate an issue and understand potential implications.

Analytics can serve as a helpful guide and show you where some issues might be, but I’m not going to pretend the conclusions are absolute.

Decisions by decisions (From the Department of Redundancy Department)

One of the reasons I wanted to look into 4^th downs at all was because I’m continually frustrated by coaches kicking field goals or punting.

Coaches are too conservative, just about any research in football has suggested as such, and so when I put this sample together, I wanted to see what my data looked like.

The first thing I did was filter all the fourth downs based on what the ‘optimal decision’ actually was.  Remember, each fourth down, based on our strategy chart, was either ‘Go for it,’ ‘Field Goal,’ or ‘Punt’, based on the action that would maximize your expected points.

So, if we sort our data by what the optimal decision should be, we can see whether NFL coaches are screwing up opportunities to punt, kick field goals, or go for it (hint – my money is on go for it)

As TMQ’s Gregg Easterbrook would exclaim, ‘Ye gods!’

The good news for NFL coaches, is that when they’re supposed to be conservative, they are fantastic about it.  In situations where coaches should be kicking a field goal or punting, they decide to do just that 97% and 99% of the time, respectively.  Amazingly optimal performance!

Of course, such high rates would suggest that our coaches are being extremely conservative, which probably seeps over into fourth downs where they should be trying to convert.  And sure enough, the abysmal 15% pass rate on fourth downs where teams should be going for it is exactly what we’d expect to see from overly conservative managers.

That means that, when faced with a fourth down where the best outcome is to go for it, coaches choose to kick away (punt or FG) about 85% of the time.

Wow.  That seems insanely high.  Making the wrong choice 85% of the time?  I feel like in most jobs those kinds of choices get you fired.  If you make 85% of the burgers wrong at McDonald’s, you’ll most definitely be out of a job.

But to give you a sense of what these failing decisions actually look like, I’ve included a sample from my data set below:

All of these are example ‘fails’ by NFL coaches when the best choice would be to go for a first down.  Some of them seem pretty obvious.  Pete Carroll and the Seahawks had 4^th and 2 from the Arizona 9 yard line and elected to kick a field goal (which by the way, they missed).  Some of them, like Dennis Allen opting for a FG from the Chargers 33 on 4^th and 6, seem a bit more arguable.

But across all those possible decisions, only 15% of them were the ‘optimal’ choice.  Even with my earlier caveats (not adjusted for team ability or game situation), that still seems like something is systematically wrong with NFL coaches.

Decisions by Field Position

So we know what type of decisions coaches mess up.  They’re too conservative and should be going for it more often.

But let’s keep going, and ask ourselves, are these decisions happening all over the field?  Are they happening more in some areas than others?

I broke down the field into four main zones, and looked at the data that way.

1. Own territory – Anywhere between your goal line and the 50 yard line
2. The ‘Maroon Zone’ – A term I borrowed as an homage to TMQ, who has consistently railed on over-conservative coaching for years.  My definition of the Maroon Zone is in opposing territory, but not as far as the opposing 35 yard line.  Too far for a field goal, but surely too close to punt!
3. FG Range – Any position between the opposing 35 yard line and the opposing 20 yard line.  From the 35 yard line a field goal would be 52 yards, which is more or less the regular range of today’s NFL kickers.  We could split hairs and more it back a few more yards, but this was where I decided to draw the line.
4. Red Zone – Anywhere from the opposing 20 yard line to the opposing goal line

So I set these bins and filtered the fourth downs.  Where on the field are teams making more suboptimal decisions?

I should’ve saved the ‘Ye Gods’ for this, huh?

One of the first things that jumps out is that coaches make the most optimal decisions in their own territory.  This makes sense, as we know our coaches are big on punting, and in their own territory, that’s more likely the right decision. (Of course, in an absolute sense, getting only two-thirds of decisions right isn’t exactly fantastic)

The other thing that jumps out is the performance in the Maroon Zone, so opposing territory but a bit too far for most field goals.  Coaches are only making the right decision about 32% of the time here.

Again, some of you might be wondering types of decisions this entails, so I’ve pulled a sampling of Maroon Zone decisions.  This table illustrates eight examples of Maroon Zone decisions from my data set, all from the first quarter of the first week of this season.  It includes the coach, matchup, down and distance, score position, decision (both actual and optimal), and grade.

Let’s take the first row, when Mike Munchak and the Titans, facing a fourth and 1 from the opposing 37 yard line, faced a decision.  You’ll see the Titans elected to pass, and that the optimal decision was to go for it.  For that ‘passing’ decision, they received a ‘1’ grade.

Contrast that with Mike McCarthy and the Packers in their game against the 49ers.  McCarthy had a decision on fourth and 3 from the 49ers 45 yard line.  At the time, the Packers were down three points.  With arguably the best quarterback in football and a stable of talented receivers, did McCarthy choose to go for it?

No, the Packers punted.  Now, you could argue that the 49ers have a great defense and field position is key and blah blah blah.  I’m not saying those arguments have no merit, I’m just saying I would’ve gone for it, and in that situation, going for it is the right move.

You may ask what happened on those plays?  What were the outcomes?  Did the Titans convert the first down?  Did the Packers punt give them great field position?

Well, frankly, I don’t care what happened.  Judging a decision based on the outcomes creates a whole set of biases which I don’t want to influence our analysis.  The goal of this is to understand whether coaches are making the right decisions, not whether those decisions ended up working out.  To me, that means we should keep the outcomes completely outside of this conversation.

Decisions by Yards to Go

So coaches aren’t going for it enough, and although they make the wrong decision most of the time whenever they’re in opposing territory, it’s at its worst when they’re beyond field goal range.

That’s interesting, if not completely unexpected.

But how is their decision-making impacted by the distance required for a first down?  Is there any difference to a coach’s decision making whether its 8 yards to go vs. 3 yards to go?

Again, not a shocking result.

When the optimal decision is a more conservative approach (like punting on a fourth and ten), coaches almost always get it right.

But as the distance to convert shrinks, performance gets remarkably worse, especially around 2-3 yards to go, when coaches are only getting it right one-fifth of the time.

Again, it’s the conservative approach that does them in.  When coaches should be trying for conversions, they’re punting the ball away or attempting a field goal.  What’s interesting is that with only one yard to go, they’re actually a bit better.  I feel like it’s a gap based on aesthetics more than anything else.   One measly yard? We can go get that! The coach may say to himself.  But push it back another three feet and it somehow becomes impossible.

Now we’ve seen just how bad NFL coaches (as a group) are when it comes to optimal 4th down decision-making.  Tomorrow, we’ll look at individual coaches to see who is the best (or least bad as the case may be).  The results are shocking…

Today is the first installment of a series of posts about 4th Down Decision-making in the NFL.  These are going to be a bit long, but extremely interesting for fans interested in the high-level analysis of the game (which should be just about everyone who comes here).

I’ve broken the entire analysis down into 3 parts:

Part 1 (today) will discuss the overall idea behind the analysis and build to a 4th Down Strategy Chart

Part 2 (tomorrow) will use that strategy chart to grade NFL coaches and show us how often the “right” decisions are made

Part 3 (Wednesday) will show the results for individual coaches and discuss potential implications of the entire analysis.

This was authored by Jared Cohen, with limited editing/input from me.  You might remember Jared from his previous posts here, specifically his timely explanation, shortly before the Super Bowl, of why running a kick out from the back of the end zone is usually a GOOD decision.  Of course, soon after that analysis, Jacoby Jones ran a kick out from the back of the end zone in the SB, resulting in a 109 yard touchdown…

Also, by way of qualifications, Jared is a:

- Two-time Jeopardy champion, and the man who brought Family Guy to life in Final Jeopardy.  You can buy his e-book about the whole experience for just $0.99 here.

- MBA from the Booth School of Business at the University of Chicago, now a management consultant at Booz & Co.

- Play-charter for Football Outsiders for the 2012 season

You can follow him on twitter at @jaredscohen.

Part 1

Always double down on eleven.

It’s a rule of thumb any blackjack player will tell you.  Applicable in almost every situation, at any casino, when your cards come up eleven and the dealer isn’t showing an Ace, you double down.  No matter how much you’re betting, no matter how bad your luck has been, no matter which random foreign country your expressionless automaton of a dealer is from, you double down on eleven.

Why?

Because it gives you the best chance at winning.

And how do we know that doubling down gives you the best chance at winning?

Because people have researched it.  People have done their homework, complete with statistics programs, random number generators and complicated looking equations (or as its known in some parts of the country, “witchcraft”)

 They even have a card which tells you what to do.  Since Blackjack is a game with well-defined rules and structure, there can be a clear strategy that, if executed, will help you win as much as possible (or, to be technically accurate, help you lose as little as possible).

While you don’t have to do what the card tells you, it’s definitely more right than your ‘gut’ instincts or homebrewed system.  It’s based on data.

Yet, some players will insist on hitting their 12 against a dealer 6.  They’ll refuse to double down on 11.  They’ll split 10s!

Simply put, they’re doing it wrong.

So how does this relate to football?  Well, I was wondering if NFL coaches are doing the exact same thing, eschewing data in favor of their own gut.

What I found was a little surprising.

Now, football is a complex game, with a lot of situations and decisions.  For this analysis, I decided to focus on what has long been a frustrating aspect of many Sundays spent with the Red Zone channel…Fourth Downs.

That shouldn’t come as a shock.  Fourth downs are the most direct view into a coach’s risk tolerance and personal philosophy.

And in thinking back to my blackjack discussion, I wondered what NFL coaches would look like if there were an optimal strategy for fourth downs.  There’s already a chart for when you’re supposed to go for a two point conversion.  If there were a basic strategy 4^th down card, how would coaches perform when compared them to it?  How close would they be to the best strategy?

That is to say, do these coaches know to double down on eleven? Or are they the guy sitting at the table refusing to split their pair of eights?

In these articles, I’ll describe the methodology behind the analysis, illustrate some results, and discuss some of the implications.

Context and Expected Points

To start things off, I wondered if anyone had already done research into optimal fourth down strategy.  I know lots of smart football fans out there have already spent time on it, so I figured it would already be established in the literature (and would save me the time of having to establish it).

Turns out it has been, and we’ll get into it in some detail, but before we get to that, we need to just establish the foundation for such an optimal strategy chart.  And that means some background in the idea of expected points.

Originally conceived back in the 1980’s, expected points has gained a fair amount of traction with the football analytics community.  Even ESPN uses it.  Here’s a little bit of their explanation, which I’m cribbing because it’s clear.

Based on statistical analysis of 10 years of NFL play-by-play data, ESPN has created a formula that assigns an “expected points” value to the team with the ball at the start of each play based on the game situation. Expected points (EP) accounts for factors such as down, distance to go, field position, home-field advantage and time remaining.

The value it puts out is on a scale from about minus-3 to 7, and it basically represents “which team is likely to score next, and how many points?” It represents the likely points not just on the current drive but also on the next drive or any subsequent drive until the score changes or the half ends. A lower value indicates a more favorable situation for the defense (i.e. fourth-and-20 from your own 1-yard line could be close to minus-3 EP), and a higher value represents a more favorable situation for the offense (i.e. first-and-goal is generally worth 6 EP).

Essentially, expected points is a way to evaluate football situations against each other.  Because each play is based on its situation (what down it is, field position, and how many yards to convert a first down), expected points serves as a normalized metric for the value of possession in any situation.  What’s more, is that after a play, you can compare the expected points values from the old and new situations, and determine how valuable the play was.  Here’s an example from ESPN’s explanation:

From your own 20-yard line, an 8-yard gain on third-and-10 is worth about minus-0.2 EPA because you don’t get a first down; the same 8 yards on third-and-7 is worth 1.4 EPA for converting a long third down and keeping the drive alive. EPA knows that not all yards are created equal.

So, using expected points as our basis, we can compare the best option (what would create the most expected points increase) for any given fourth down situation.  And when I say we, I mean Brian Burke.

Burke has already done a fair amount of research on the optimal fourth down strategy, which I’ve leveraged as the base for this analysis.

Using expected points values and historical data, Burke has done some prior research on what the ‘optimal’ fourth down decision should be (FG, punt, or going for it).  Depending on your field position, and yards to go, he put together a view of what decision would be best for a given fourth down.  His chart of that strategy is below:

Depending on where your given fourth down situation falls, the best option is illustrated here.  For example, if you had a fourth down and two yards to go on your opponent’s 10 yard line, the recommended option would be to go for it.  Alternatively, if you faced  a fourth down and had eight yards to go to convert it from your opponent’s 10 yard line, you should kick a field goal.

Make sense?

This chart can serve as the basis for our basic fourth down strategy chart.

Put another way, based on my rough transcription, it would look something like this.  Apologies for the lack of labels, but:

- The columns show yards to go (so 1 = 4th and 1)

- The rows show yard-line on the field, from your own end zone (so 5 = own 5 yard line, 95 = opponents 5 yard line).

- Together, cell 2 x 2 means shows the correct decision when faced with 4th and 2 from your own 2 yard line.

Looks just like a blackjack strategy card, doesn’t it?

Note that there are a few strange suggestions in the card which are most likely just statistical anomalies that will disappear with more data.  The most obvious example of this is cell 2 x 98 (or what to do when faced with a 4th and 2 from the opponents 2 yard line).  That chart says kick the field goal, but it makes very little sense to kick from the 2 yard line while going for it from the 1 and 3-6 yard lines.

Also, in practice, teams could adjust the card each week to account for the relative strength of the opposing defense.  If you’re playing a very weak defense, you’re odds of converting 4th downs goes up, so you’d see a few more Green blocks above.

Now that we have an “optimal strategy”, or at least a “default”, we can compare it to real life decisions and see how often coaches make the right call.  Come back tomorrow for the results in Part 2.

As you might have expected after Wednesday’s post, I have also put a chart together that illustrates the Eagles Offense’s evolution in personnel over the Andy Reid era.  Rather than doing a pure positional chart like before (I may still put that together for the offense), I decided to illustrate the Top 5 players from each year (by yards from scrimmage).

This gives us a better idea of the general focus of the offense each season, as well as showing the ebb and flow of each player’s career with the Eagles.  Below is the chart.  Please note that the only data included is for years in which the subject player ranked in the top 5 of yards from scrimmage for the Eagles.  So if a player either doesn’t feature on the chart or has a year for which they are listed at 0 yards, it just means they didn’t rank in the top 5 of the team that year, not that they recorded 0 yards that year.  Also, this highlights rushing and receiving yards, so QBs are not represented beyond their rushing contributions.  Click to enlarge.

I know that’s not the easiest chart to read, so I labeled the major contributors.  In general, as the chart moves from left to right, the legend (right) moves from the bottom to the top.  Additionally, here is the data:

Takeaways:

- Overall, we can see the gradual increase in total yards for the top 5 offensive players.  As I illustrated last week, the Eagles offense improved over Andy Reid’s tenure, and not just as a result of overall league offensive inflation.

- The increase in overall yards coincides with an increase in the % of Total (seen at the bottom of the data table).  This shows how the Eagles offense became more “playmaker” focused.  In Andy Reid’s first few years, the distribution of offensive yards and touches was more widespread than in his later years.  Obviously, the early years’ offenses did not include anywhere near the same level of skill as the later years’.

- Brian Westbrook jumps out immediately, and clearly held the largest non-QB offensive share during the Andy Reid era.  Notably, LeSean McCoy looks like he had the potential to match Westbrook’s contributions, if Andy had continued to coach the team.  It always bothered me that Andy didn’t feature Shady in the same way he did Westbrook.  Part of that is because the Eagles now have DeSean and Maclin, and part is due to the fact the Shady is not as good a receiver as Westbrook was.

However, I would like to see Shady used as a receiver more often, and not just on designed screens or check-downs.

- As I already mentioned, the chart highlights the clear improvement in offensive talent over the course of the Andy Reid era.  The main early contributors were James Thrash, Duce Staley, and Todd Pinkston; the late ones Shady, Jackson, and Maclin, with Westbrook in the middle.

Note though, that the Eagles best years under Reid featured Duce Staley as the biggest offensive weapon (outside of McNabb).

- The chart also illustrates the relative cameos made by random players like Dorsey Levens, Donte Stallworth, Antonio Freeman, Hank Baskett, and Greg Lewis.  Remember them?  They each had at one season in which they were a “top 5″ offensive weapon for the Eagles.

- 2008 stands out as a major transition year for the offense;  before then Westbrook was THE weapon, while after marked the fast transition to the current Eagles offensive era.

- At the moment, I expect the Chip Kelly era to bring more equality to the offensive yards distribution.  That’s obviously speculative, but I believe we will see the “Top 5% of total” decline over the next year or two.

As I illustrated earlier this week, the Eagles’ defense under Andy Reid was MUCH stronger from 2000-2004 than it was thereafter.  As a reminder, here is the team’s Points Allowed performance from 2000-2012.  The “LAVG-PPGA” shows how many FEWER points per game than the league average the Eagles allowed that year.  So for the 2000 season, the Eagles allowed 5.4 points per game less than the league average.  The “Def+%” shows that margin divided by the league average, which gives us the percentage difference (which accounts for the offensive inflation over the years).

So the question is, what happened after 2004?  While the Jim Johnson effect can be clearly seen after his departure after the 2008 season, that doesn’t explain the team’s performance in 2005 and 2006.

Was this just bad luck?  Something else?

Well to begin to answer that question, I felt like it’d be useful to take a look at how the defensive personnel evolved over time.  To do that, I prepared a graphic that shows the Eagles defensive starters for all even years from 2002-2010 (5 seasons).  Additionally, I listed (in parenthesis) each player’s Approximate Value for that season as defined by Pro-Football-reference.com.  Note that this is a far from perfect measure, especially on the defensive side of the ball, but it gives us a good idea of who the biggest contributors were each year.  Players with an AV of 6 of below are shown as Red.  An AV of 7-9 is Yellow, with 10+ getting green.  For quick reference, the top two circles on each line (2002 and 2004) mark the “peak” era.  Click to enlarge if you can’t read it as is.

So what can we see?

Unfortunately, it doesn’t present as clear an answer as I had hoped.  However, if you look closely, I think you can begin to see a potential factor; namely, the Elite players.

While I won’t go into overall football philosophy here (that’s its own post), in general, I am of the belief that you SCORE points with scheme, and PREVENT them with talent.

Now that’s an overly simplistic description, and obviously you need talent to score and a good scheme to prevent points, but at a high level, that’s how things shake out (mostly due to the offense’s inherent knowledge advantage, in that they know the play and the defense doesn’t).

How can we apply that here?

Well as you can see, the “peak” Eagles defense’ all included truly Elite player performances.

From 2000-2004, you’ve got Troy Vincent, Hugh Douglas, Brian Dawkins, Lito Sheppard, and Jeremiah Trotter (not shown since his best years came in ODD years) all turning in truly Elite performances (not necessarily every year).  When those players were in their prime, they were easily among the best at their positions in the entire league.

The failure to replace these players with others of similar skill is one of the BIGGEST FAILINGS of the Andy Reid FO regime.

As you can see above, after 2004 (so the bottom three circles on each position line), the best Eagles defenders were Trent Cole, Asante Samuel, Quintin Mikell, and Brian Dawkins (though below his peak).  While each of those players was very good, they really did not come close to matching the peak years of the 2000-2004 players I highlighted above.

So what now?

Well it’s clear the Eagles’ current defense needs more top-end talent.  As of this moment, the only player that looks like he has the ability to become “elite” is Fletcher Cox.  As I just showed, that’s not nearly enough.  Unfortunately, it looks very unlikely that this year’s draft produced any more potential impact players for the defense.  While I admire and support sticking 100% to BPA (my definition, not the NFL’s…see TPR), at some point, the Eagles will have to find impact contributors on defense.  Ideally, next year’s BPA at each spot will be a defensive player.  If not, though, the Eagles will have to move around to ensure that’s the case.

Today I’ll continue in the same vein as yesterday’s post, this time broadening our scope to include the entire league, rather than focusing on just the Eagles.

First, however, I have to acknowledge the news yesterday that Donovan McNabb will be retiring as an Eagle in the fall (looks like it will likely happen before the KC game so Andy is there).  Objectively speaking, McNabb was a fantastic QB who every Eagles fan should love.  I’m not going to go through his numbers today, but it’s safe to say he’s one of the more under-appreciated stars of the league, due entirely to the lack of a Super Bowl ring.

The NFL, more than any other league (thought the NBA is close), judges its best players (QBs) almost entirely on Championship performance.  In my opinion, that’s ridiculous; but it is what it is.  If McNabb takes home that SB ring (he was damn close), both he and Andy become true sports royalty in Philadelphia.

Although I typically stay far away from any conspiracy theory, you will never convince me that the Patriots didn’t cheat in the Super Bowl.  While that is a subject for another day, given when/how they were found out and the subsequent destruction of the evidence (shady and inexcusable), there is strong logical support for the Super Bowl cheating theory. If that doesn’t happen, McNabb is a HOFer.

We should all treat him as such anyway.

Back to the stats.

Now let’s take a look back at the league, starting with the 2000 season.  Yesterday, in an effort to discern just how good each Eagles offense and defense was, I measured every team against the rest of the league from that year, presenting the results in a +- % format.

Two caveats before we get to the best defenses.  One, the league averages INCLUDE each subject team; so the historically great teams, in fact, outperformed the league by slightly more than what is shown below.  Two, I did not go through every team’s season to see if they “shut it down” after clinching a playoff berth.  Some likely did, which would have an effect (relatively small) on the subsequent rankings.

Also, what we are looking at here is Points Allowed.  This is a little different from looking at the “best defenses”, so perhaps it’s fairer to say we are ranking the best “team point prevention seasons”.

So which teams had the best point-prevention seasons?  Here is a table of the top 25 since the 2000 season.  Teams highlighted yellow won the Super Bowl.

The 4th column above “LAVG-PPGA” just shows the point margin for each team above (actually below in this case) the league average.

As we can see, there’s a lot of yellow (SB champs) and a lot of Green (Eagles), but no overlap..

• The 2000 Baltimore defense, which we all knew was great, was a full 50% better than the rest of the league.  As I mentioned above, if we remove the Ravens from the league average that year, their performance would be even better, breaking the +50% mark.

• The Buccaneers team that beat the Eagles in the NFC title game was a HISTORICALLY great defensive team.  There was a lot of hand-wringing in Philly after the game about how inept the offense was (particularly the receivers), but the simple fact is, the Eagles ran into a figurative defensive wall.  One almost as strong as that famed Baltimore defense mentioned above.

• Also of interest is the placement of Green Bay ’10.  While Aaron Rodgers gets a lot of credit (as he should), the strength of that team was really the defense.

• It might also be strange to see New England featured twice on the list (including the ’03 SB team), but the early Belichick era was really built on that side of the ball.  Notably, despite all their regular season success, the Patriots last SB win came in ’05, during their “defensive” era, as opposed to the “offensive” era we’ve seen from them more recently.  To be fair, the “offensive” Patriots did GET TO the SB twice, losing close games to the Giants in each.

How about the Offenses?

As I did with the defense, here I am looking purely at Points Scored.  The same caveats apply.  The only thing I’ve added is Red highlighting for Super Bowl LOSERS.

While we didn’t need this table to tell us the 2007 Patriots were a great offense, it really is incredible just how much better than everyone else they were.  Even accounting for points inflation, no team since 2000 (and I’d be surprised if any team in modern history) comes close.  The 2000 Rams were also an amazing offense, 63% better than league average, and yet that team is still 7% below the 2007 Patriots mark.

• Perhaps most surprising here is the lack of yellow (i.e. Super Bowl Winners).  As I’ve explained before, it is NECESSARY to have an above-average offense if you want to win the Super Bowl.  HOWEVER, a truly GREAT offense guarantees you nothing.  Contrast this chart (1 winner in the top 25) with the Defense chart above (5 winners in the top 25), and it looks like, all other things being equal, having a Great defense trumps having a Great offense.

• The Eagles, obviously, do not appear on this list.  For all of Andy Reid’s offensive skill (and he has a lot), that never translated to a truly great offense.  Looking at yesterday’s tables, the Eagles never really came that close either.

• Again, the Patriots “offensive” era shows up a lot here, though it hasn’t translated to more Super Bowl wins.

• Lastly, there are a couple of surprising teams that people might have forgotten about:

               Kansas City ’02-’04: Trent Green and Priest Holmes

               Oakland ’00: Rich Gannon and Tim Brown

               Minnesota ’09: Favre and AP (Ok, you probably didn’t forget about them)

               Denver ’00: Brian Griese and Mike Anderson (Wow…)

Last week I showed a couple of tables that illustrated the relative performance of each Eagles team under Andy Reid (other than his first year).  To do that, I compared the PPG and Points Allowed Per Game to EVERY other team from the past 10 years.  The results were interesting, and showed that the Eagles typically performed very well in at least one of those categories; but also showed that while offensive performance trended up over time, the defense fell off by a larger amount.

The problem, though, is that the analysis did not take into account the annual league-wide scoring fluctuations, and specifically, the general increase in scoring over the past 13 years.  I’ve done a similar analysis today, but this one shows how each team performed relative to the rest of the league FOR THAT YEAR.

Before I get to the charts, here’s an example of what I did (it’s very simple):

The 2002 Eagles scored 25.9 PPG.  The NFL average that year was 21.7.

The Eagles scored 4.2 PPG more than the league average or 20% (4.2/21.7).

The tables below will show the % over or under league average for each Eagles team.

First, the Eagles Offense:

As we can see above, after his first year, Andy Reid’s offense only finished below-average 3 times, with 2012 marking the only really poor performance.  Interestingly, the best offensive years for the Eagles were in 2009 and 2010, when the team was 25% better than the league average.

The 2004 Eagles team, the Super Bowl team, was just 12% better than league average.  However, that team (after clinching) shut it down for the last two games of the season, scoring a combined 17 points in losses against the Rams and Bengals.  If we remove those two games, the 2004 Eagles averaged 26.4 PPG, or 22.5% better than league average.    While that is a very strong performance, it still doesn’t rank better than the ’09 or ’10 teams, and is just above ’02 and ’06 teams.

Taking a step back, we can compare the “Andy Reid Peak” to the rest of his tenure and get an idea of how things changed.  For this, I’m going to ignore last season, since it was a clear outlier.

Andy Reid Peak (’00-’04) – The Offense averaged 2.4 PPG more than the league average.

After Peak (’05-’11) – The Offense averaged 2.8 PPG more than the league average.

Or put differently, during The Peak the offense, on average, was 11% better than league average.  After the Peak, the offense was 13% better than league average.

So over time, the Eagles’ offense got better (which we knew from last week), but by a relatively small margin.

Now let’s look at the defense:

This table shows a much clearer break between the “peak” and “after-peak”.  Four of Andy Reid’s best defensive performances (and 5 of the top 6) came during the 5 seasons “Peak” stretch.  During this time, the Eagles defense allowed an average of 5.5 FEWER PPG THAN LEAGUE AVERAGE.  That’s a truly amazing run of performance.  On a percentage basis, the team was, on average, 26% better than the league-wide average.

After the peak, the Eagles allowed an average of 0.5 fewer points per game (2%) than the league average, which means the Eagles went from being a historically great defense (from ’00-’04) to being an average one.

Here is a table showing the performance of both the offense and defense side-by-side, and a graph showing the performance of each over time:

Here is another chart, which hopefully provides a clear illustration of the overall performance trend for both the offense and defense.

This chart provides the clearest picture yet of the overall shift in team performance as time passed.  While it’s not as easy to see as I had hoped, the slope of the defensive line (red) is much larger (absolute value) than the offensive line (blue).  That means the team’s offensive gains were MORE than offset by corresponding drops in defensive performance.

Tomorrow I’ll show you how the best offenses and defenses since 2000 and how they stack up when adjusted for league average.  Hint: the 2007 Patriots were OUTRAGEOUSLY good on offense (which we knew), but so were the 2000 Rams (who everyone remembers but forgets just how dominant that offense was).

UPDATE: For those wondering, next week I’ll post the same stats adjusted by annual league average.  Similar story, but it clears up some of the inflation and year-to-year comparison issues.

First, you’ll notice the site looks a bit different today.  I’ve been meaning to change it for a while; hopefully this is easier to read.  I’m not happy with the entire layout, so you may notice more changes soon.  In any case, if it’s not an improvement, please let me know.

Now then, where were we?

Right, the Andy Reid Peak, which ended after the 2004 season…

Below is a table showing the top 30 best defenses (lowest PPG allowed) in my data set.  Remember, the data set is the last 10 seasons (320 teams) PLUS the 2000-2002 Eagles teams, for a total of 323 teams.  In the table, I’ve highlighted the Eagles in green.  Also, I’ve highlighted Super Bowl Champions in yellow.

These are, roughly, the top 10% of all defenses.  Note that I have not included the rest of the league for the 2000-2002 seasons (not as easy as you’d think, for reasons I won’t explain here).  If I had, I believe there’d be 5-6 defenses that rank above the 2004 Eagles in this chart (including the outrageous 2000 Ravens, who allowed just 10.3 PPG).

In any case, including those years would actually IMPROVE the Eagles percentile rank here, so the point remains: the biggest strength of the Andy Reid Peak teams was defense.  Jim Johnson was with the team through the 2008 season, so the drop-off after 2004 is not related to coaching.

I’ll go into more detail about the drop-off next week (once I’m finished looking for potential explanations).  Today, though, is just about illustrating how good the Andy Reid Eagles were at their best.

How about offense?

Andy Reid is known as an “offensive” coach, so how was his team’s performance on that side of the ball?

The Eagles’ best offensive performance (PPG) under Reid was actually in 2010 (the Vick outlier season).  That year, the team scored 27.4 PPG, good enough for 27th overall in my data set (92nd Percentile).  Note that this was NOT during the “Andy Reid Peak”.

In fact, the best Andy Reid teams featured relatively average offenses.  Below is a table showing each Eagles team from 2000-2012 (I’m ignoring Year 1 for obvious reasons).  The first column shows that team’s offensive percentile ranking within my data set.  I’ve bolded the “Peak Era” teams.

Overall, Andy’s reputation appears justified.  6 of his 13 teams here finished in the top 25% offensively.  Three more finished better than average.

However, notice that the 2001 Eagles managed to win more games than the 2010 Eagles despite scoring SIX fewer points per game.  That’s a huge difference in performance.  There was some offensive inflation across the league over this time period, but nowhere near enough to account for the degree of change we see above.

I’ll leave it there for today, since I want to focus on the positive.  Next week, we’ll take a closer look at the relative trade-offs Reid appears to have made (sacrificing defense for offense) and if we can learn anything from that about overall team construction (I touched on this in the Necessary Conditions post if you want to get a head start).

I’ve spent a lot of time talking about how bad the Eagles were last year.  I do, however, want to spend some time on the good years.  Just how good were the Andy Reid Eagles at their peak?

To figure that out, we obviously have to first decide when the “peak” was.  Which Andy Reid team was best?

The quick answer would be 2004, since that team went to the Super Bowl (and lost by a field goal to a team that may or may not have cheated).  Indeed, the 2004 Eagles were very good.  As I’ve shown, Point Differential is the best statistical indicator of team performance, and the 2004 Eagles recorded 124 more points than their opponents.  Over the past 10 years, that leaves them in the 87th %tile, meaning that team was VERY good (obviously).

Quick note:  I’ve added the 2000-2002 Eagles teams to my data set, so from now on the data will include the last 10 years PLUS those 3 Eagles teams, meaning there are 323 total team season in the set.

HOWEVER, that was not the best team performance under Andy Reid.  In fact, the Eagles surpassed that +124 mark twice during Reid’s tenure; in 2001 (+135) and 2002 (+174).

The 2002 Eagles team, with PD of +174, ranks 12th overall in the entire data set, better than 96% of all teams during that timeframe (click to enlarge).

Additionally, the 2002 team had a TO Differential of +14, better than either the 2001 team (+9) or the 2004 Super Bowl team (+6.)

The Sack Differential points to 2002 as well, with that team registering 19 more sacks than their opponents, compared to +10 for the 2004 team and +5 for 2001.

This is a long way of saying that the 2002 Eagles team was, in my opinion (though largely supported by the data), the “best” of the Andy Reid era.  Also, it’s pretty clear that the Eagles “peak was from 2001-2004.  That itself will not surprise anyone.

What I find most shocking is that the last year of the Andy Reid “peak” was nearly 10 years ago…

It was definitely time for a change.

Lastly, for today, I’ll leave you with the Point Differential per year for the Eagles under Reid (1999 excluded).  As you can see, there’s a pretty definitive down-trend over nearly the entire timeframe.

As I mentioned at the top, I’m going to spend some time illustrating how GOOD those Eagles teams were (2001-2004).  Additionally, I’ll be looking for potential causes of the long-term decline in team performance.

No great insights today, but I will give you a few charts to look at.  After yesterday’s post, I decided to go through and chart the Eagles’ performance over the last 10 years with several different statistics.  Each chart tells a piece of the “Andy Reid Era” story, some of which we’ve covered, some of which we haven’t.

First up is the defensive performance.  By that, I mean Points Against.  There are a number of variable that go into defensive performance, so summarizing it with just Points Against is incomplete, but nonetheless, it’s an interesting chart.  This chart has 2 axes (is that the plural of axis?), with Wins on the left and PA on the right.  Wins are the blue line.

Given what we know about the correlation between Point Differential and Wins, we should expect to see something resembling an inverse relationship here (i.e. PA goes up = Wins go down).  We do see some of that, but from ’06-’09 that relationship doesn’t hold.  The biggest takeaway here is just how bad (and anomalous) last year’s performance was.  From 2003 to 20011, the average Points Against for the Eagles was just 20.11, with a high of 24.3 in 2005.  Last year the team allowed 27.8 points per game, more than a full touchdown per game over the long-term average.

UPDATE: I added the same chart below, but reversed the secondary Axis to make it a bit easier to read (thanks to a commenter).  Here, we should see a positive relationship.  Again the takeaway is that we see a bit more deviation than we’d expect, especially from ’06-’09 (and from 2010-2011).

How about Points For (Wins are the blue line again):

Here the relationship we expect to see (positive), is much clearer and more consistent.  While they are both strongly correlated with winning, Points For/Wins is, in fact, the stronger relationship.

This should be somewhat encouraging to Eagles fans, since Chip Kelly is an “offensive” coach, and the team used its top draft choices on that side of the ball.

Remember, based on the last 10 years, having an above average offense is a NECESSARY condition for winning the Super Bowl.  Having an above-average defense IS NOT.

Here is a slightly different chart.  This shows annual turnovers forced and surrendered.

As I covered yesterday, the 2011 and 2012 Eagles performed far worse than the team’s long term average.  Last year, in particular, reflects significant outliers for both measures (negatively), which led to the historically bad TO Differential.

Speaking of TO Differential (I know I’ve spent a lot of time on it), here is the histogram for all teams from 2003-2012.  The red bar is where the 2012 Eagles are located.  I may have run this chart before, but it’s ridiculous, so I’m doing it again.  Remember, the whole sample includes 320 seasons.  The height of each bar (the Y-Axis) represents how many teams finished a season with that TO Differential.

Click to enlarge.  That’s what I mean when I say historically bad.

Now that I’ve figured out how to do reasonable histograms in the new Excel (Microsoft took away the statistics tools), I hope to make a few more that will provide a good visual illustration of just how bad/good the Eagles of 2012 were.  I’ll also run them for Andy Reid’s better years, which will give us an idea of just how good the team was when it “peaked”.
